Grinding wheels (Ø x bore):355 x 25.4 mm

No-load speed:3700 rpm

Rated input power:2300 W

Description:

Powerful metal chop saw for cutting of profiles, pipes and rods made of steel, NF metals, iron and cast profiles
Quick clamping device with variable mitre setting for angled cuts from -15° to 45°
Large handle transversal to the cutting axis for optimum power transmission while cutting
Adjustable cutting depth limiter for optimum use of the cutting disc
Easy, fast disc change with spindle lock
Maximum user safety: swivelling cutting guard, adjustable spark deflector sheet and rubberised base for safe cutting
Safety switch for protection against accidental start up
Robust, large machine table with practical storage for hexagonal wrenches
Easy to transport due to built-in handle and locking device
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.

Technical Data:

Characteristics
Grinding wheels (Ø x bore)355 x 25.4 mm
No-load speed3700 rpm
Rated input power2300 W
Max. cutting capacity round tube132 mm
Max. cutting capacity square tube120 x 120 mm
Max. cutting capacity rectangular tube100 x 208 mm
Max. cutting capacity L-profile150 x 150 mm
Dimensions of the base plate456 x 256 mm
Transport height394 mm
Weight16.8 kg
Cable length4 m

Scope of Delivery:

Hexagonal wrench
Inner support flange
Flange nut
Cutting disc 355 mm

Product Code: CS22-355
